Welcome to the NaviNet & PyPilot DIY Autopilot Community!
This group was created to help sailors share knowledge, experience, and support each other in building a powerful, affordable marine autopilot based on the acclaimed PyPilot software — originally developed by sean depagnier, and proven over tens of thousands of nautical miles worldwide.
NaviNet has developed a dedicated hardware platform and a modern web-based application that includes:
• MFD capabilities
• Support for NMEA2000, SeaTalkNG, and NMEA0183
• Seamless integration with PyPilot , openCPN , and any chart plotters
Our goal is to give every sailor the option to build their own autopilot at a budget-friendly cost using high-quality hardware components that can be purchased directly by group members.
I am here to guide, support, and collaborate — and to hear your ideas for improvements, features, and enhancements to the system.
Join us : https://www.facebook.com/groups/1677078816603405/
for pypilot open source autopilot FREE software visit
Welcome aboard, and fair winds!
BTP1- basic Tiny PyPilot -full kit at 200$
MDC20A - 90$
MDC20A mid-power motor driver – fully assembled
Drive any type of Rudder motor up to 20 Amp.
solenoid port
Rudder feedback port
optionaly RS422 NMEA0183 port
MCU components kit - 70$
Raspberry Pi Zero W
• DC/DC power supply
• IMU sensor – ICM-20948
• 220µF capacitor
• 32GB SD card
• Pin headers
MCU PCB - 40$
• MCU -Main computer PCB
optionally enclosure kit -70$
MCU waterproof IP67 enclosure
MDC20A enclosure
2 x M12 male head adapter
24 x PCB terminal block
ANP1- Advance NaviNet & PyPilot - full kit - 620 $
BTP1- basic Tiny PyPilot + enclosure kit + ESP32 web application
RTG1-Advance NaviNet & PyPilot - Ready to go - 820 $
